* AC charging stations are evolving from 6.6 kW to 11 kW, with a future shift towards 22 kW.

* DC charging module power has doubled from 20 kW to 40 kW, significantly reducing charging times.

* Ultra-fast charging stations (Superchargers) have jumped from 250 kW to 360 kW and beyond.

These advancements, while promising, introduce significant technical challenges—grid stability, high-power density, dynamic load handling, and cost-effective testing solutions. To ensure reliable performance, manufacturers must rigorously test charging stations under real-world conditions. This is where ITECH’s EV SE Testing Solutions come into play.

Application: Key Testing Challenges in Ultra-Fast Charging

To develop next-generation charging solutions, manufacturers must address several critical aspects:

✅ Grid Compatibility & Power Stability – As charging power increases, ensuring seamless integration with the power grid is crucial. Chargers must operate reliably under fluctuating voltage and frequency conditions.

✅ High Power Density Testing – The growing demand for compact, high-power charging modules requires testing solutions that can efficiently handle increasing power levels without excessive space and cost.

✅ Cost-Effective & Scalable Testing – Many traditional testing setups require multiple devices to achieve higher power levels, leading to increased costs and complexity.

✅ Space Optimization – Ultra-fast chargers require high-power test setups. Efficient space utilization in testing labs is essential, especially for 360 kW+ Supercharger testing.

Solution: ITECH’s High-Power, Cost-Effective Testing Solutions

1. AC Charging Station Testing: Higher Power Density, Greater Efficiency

- Power Trend: 6.6 kW (Before) → 11 kW (Now) → 22 kW (Future)

- ITECH’s Advantage: IT7800/7900E/7900EP Grid Simulator (3U/21 kVA) provides high-power density for AC charging station testing and simulates real-world grid conditions with precise voltage and frequency control.

Compact design saves space while delivering high power output.

2. DC Charging Module Testing: More Power in a Single Device

-Power Trend: 20 kW (Before) → 40 kW (Latest)

-ITECH’s Advantage: IT6600C Bidirectional DC Power Supply (3U/42 kW).

A single IT6600C meets the latest high-power DC charging module testing requirements and eliminates the need for multiple battery simulators, significantly reducing cost and complexity.

Offers bidirectional power flow for precise energy testing.

3. Supercharger Testing: Industry-Leading High-Power Testing in a Single Cabinet

-Power Trend: 250 kW (Before) → 360 kW (Latest)

-ITECH’s Advantage: IT6600C bidirectional DC power supply for 360–400 kW Supercharger Testing

It meets the full power requirement for ultra-fast chargers. Compact design saves space and reduces cost compared to traditional multi-cabinet setups. Meanwhile, it delivers high-precision testing for next-gen ultra-fast charging stations.

Why Choose ITECH Electronics ?

* Industry-Leading Power Density – ITECH solutions offer high power in compact designs, optimizing testing efficiency.

* Scalability & Cost Efficiency – Reduce costs by eliminating the need for multiple testing devices.

* Future-Proof Testing – Designed for the next generation of ultra-fast EV chargers.

* Versatile & Realistic Testing – Simulate real-world grid conditions and vehicle charging behaviors.

As the EV industry pushes toward higher power and faster charging, testing technology must evolve to keep up. ITECH’s EV SE Testing Solutions provide high-power, cost-efficient, and space-saving solutions for AC, DC, and Supercharger development.

With ITECH’s cutting-edge technology, manufacturers can accelerate innovation, enhance reliability, and ensure their products meet the evolving demands of the EV charging industry.
